1N965B 500mW 15V Voltage Regulator Zener Diode Motorola®

1N965B 500mW 15V Voltage Regulator Zener Diode Motorola®

Manufacturer: Motorola®
Part Number: 1N965B
Amps: 8.5
Voltage: 15
Watts: .5
Ohms: 16
Tolerance (%): 5
Package: DO-35 / DO-204AH
Mounting: Through Hole
Lead/Terminal Type: Axial
Number Leads/Terminals: 2
Color: Silver / Black
Temperature: -65 to 200°C
Termination Method: Solder

Price: $0.10
428 available for immediate delivery
