SPT7835SIS A/D Converter IC SPT

SPT7835SIS A/D Converter IC SPT

Manufacturer: SPT
Part Number: SPT7835SIS
Package: SOIC
Number Leads/Terminals: 28

Price: $0.85
260 available for immediate delivery
Code: G421APF05
Weight: 0.03oz ONZ
Volume Pricing
Quantity Price Each
1-9$0.85
10-99$0.75
100+$0.65
