1N5338B 240mA 5.1V Zener Voltage Regulator Surmetic 40 Motorola®

1N5338B 240mA 5.1V Zener Voltage Regulator Surmetic 40 Motorola®

Manufacturer: Motorola® (On Semiconductor®)
Part Number: 1N5338B
Amps: .24
Voltage: 5.1
Watts: .5
Tolerance (%): 5
Mounting: Through Hole
Lead/Terminal Type: Axial
Number Leads/Terminals: 2
Material: Thermoplastic
Color: Black
Temperature: -65 to 200°C
Shape: Round
Termination Method: Solder
Size (mm): 8.89 x 3.68

Price: $0.20
1186 available for immediate delivery
Code: DI252PD
