745653-3 Backshell Cable Clamp Connector 90 Degree Amp
Manufacturer: Molex
Part Number: 87204-6362
Amps: 1
Voltage: 300
Mounting: Through Hole
Lead/Terminal Type: Right Angle
Number Leads/Terminals: 25
Temperature: 85
Obsolete: Yes
Shape: Rectangle
Pitch (mm): 2.77
Price: $3.00
180 available for immediate delivery
Code: K150APN03
Weight: 0.50oz
Additional Information
D-Subminiature ConnectorsI/O PCB Female Receptacle
OBSOLETE
Features:
- Gold Flashed Leads
- Shielded
- Right Angle
Current-Maximum: 1.0A
Voltage-Maximum: 300V
Operating Temperature: -55 deg. C to 85 deg. C
Number of Circuits: 25
Type: Receptacle
Application: Wire-to-Board
Orientation: Right Angle
Mates With: 87203
Dimensions:
Overall Length: 53.14mm (2.09")
Overall Depth: 18.55mm (0.73")
Overall Height: 15.47mm (0.61")
Pitch Mating Interface: 2.77mm (0.109")
Manufactured by: Molex
Part Number: 87204-6362
Full Datasheet: Molex Wire to Board Receptacle Connector 0872046362
