79M05 MC79M05CDT 500mA -5V Surface Mount Voltage Regulator Motorola®

79M05 MC79M05CDT 500mA -5V Surface Mount Voltage Regulator Motorola®

Manufacturer: Motorola® (On Semiconductor®)
Part Number: MC79M05CDT
Amps: .5
Voltage: -5
Package: DPAK-3
Mounting: Surface Mount
Number Leads/Terminals: 3
Color: Black
Temperature: -40 to 125°C
Termination Method: Solder

Price: $0.60
44 available for immediate delivery
Code: G107PE06
Weight: 0.02oz ONZ
Volume Pricing
Quantity Price Each
1-9$0.60
10+$0.55
