1N4465 JANTX1N4465US Military Zener Diode Microsemi

1N4465 JANTX1N4465US Military Zener Diode Microsemi

Manufacturer: Microsemi
Part Number: JANTX1N4465US
Voltage: 10
Watts: 1.5
Package: D-5A
Lead/Terminal Type: Surface Mount
Military Spec: Yes

Price: $20.00
300 available for immediate delivery
Code: G337APF03
Weight: 0.01oz ONZ

First Class Mail Shipping Costs:

Order Total Minimum
 Order Total Maximum
 USA First Class Shipping Rates
$00.01
 $25.00
 $5.85
$25.01
 $35.00
 $6.85
$35.01
 $45.00
 $8.85
$45.01
 $55.00
 $9.85
$55.01
 $75.01
 $11.85
$75.01
 $100.00
 $12.85
$100.01
 $200.00
 $14.85
$200.01
 $300.00
 $15.85
$300.01
 $500.00
 $17.85
$500.01
 +
 $18.85

Priority Mail Shipping Costs:

Order Total Minimum
 Order Total Maximum
 USA Priority Mail Shipping Rates
$00.01
 $25.00
 $10.50
$25.01
 $35.00
 $11.50
$35.01
 $45.00
 $12.50
$45.01
 $55.00
 $13.50
$55.01
 $75.01
 $14.50
$75.01
 $100.00
 $16.50
$100.01
 $200.00
 $18.50
$200.01
 $300.00
 $21.50
$300.01
 $500.00
 $24.50
$500.01
 +
 $25.50

Canada First Class International (see Shipping page for exclusions)

Order Total Minimum
 Order Total Maximum
 Canada First Class International
$00.01
 $45.00
 $15.95
$45.01
 $90.00
 $29.95
$90.01
 $150.00
 $49.95
$150.01
 $300.00
 $59.95
$300.01
 $700.00
 $79.95
$700.01
 $2000.00
 $99.95

Canada Priority Mail (see Shipping page for exclusions)

Order Total Minimum
 Order Total Maximum
 Canada Priority Mail
$00.01
 $45.00
 $36.95
$45.01
 $90.00
 $45.95
$90.01
 $150.00
 $59.95
$150.01
 $300.00
 $79.95
$300.01
 $700.00
 $99.95
$700.01
 $2000.00
 $109.95

International - Outside US / CA (see Shipping page for exclusions)

Order Total Minimum
 Order Total Maximum
 International - Outside US / CA
$100.00
 $150.00
 $79.95
$150.01
 $300.00
 $99.95
$300.01
 $500.00
 $139.95
$500.01
 $1000.00
 $169.95
  View shipping costs

Additional Information

Military Zener Diodes
MIL-PRF-19500/406

Features:
- Voidless-Hermetically Sealed Glass Package
- Triple Layer Passivation
- Internal "Category I" Metallurgical Bonds

Nominal Zener Voltage: 10V
Test Current: 25.0mA
Maximum Dynamic Impedance (ZZT @ IZT): 5 ohms
Maximum Knee Impedance @ .25mA (ZZK @ IZK): 500 ohm
Maximum Reverse Current @ 8.0V (IR @ VR): .30uA
Maximum Continuous Current: 143mA
Surge Current @ 8.3ms sq. wave: 1.4A

Dimensions: 5.08mm x 2.67mm(.168" x .105")

Manufactured by: Microsemi
Part Number: JANTX1N4465US

Full Datasheet: JANTX1N4465US Military Zener Diode
