POL-15033 Off-Line Switch Mode Transformer Premier Magnetics

POL-15033 Off-Line Switch Mode Transformer Premier Magnetics

Manufacturer: Premier Magnetics
Part Number: POL-15033
Inductance (uH): 600
Number Leads/Terminals: 12

Price: $6.50
355 available for immediate delivery
Code: HW225PE05
Weight: 1.52oz ONZ
Volume Pricing
Quantity Price Each
1-9$6.50
10-99$6.25
100+$6.00
