10A 24V DPDT Miniature Power Relay Sealed Zettler® AZ2732-053-52

10A 24V DPDT Miniature Power Relay Sealed Zettler® AZ2732-053-52

Manufacturer: Zettler®
Part Number: AZ2732-053-52
Amps: 10
Voltage: 24
Tolerance (%): 10
Mounting: Through Hole
Lead/Terminal Type: PC Pin
Number Leads/Terminals: 8
Material: PBT
Color: Black
Temperature: -55 to 80°C
Obsolete: Yes
Shape: Rectangular / Box
Termination Method: Solder
Size (mm): 28.1 x 12.6 x 26.1

Price: $8.00
45 available for immediate delivery
Code: X284APW02
Weight: 0.50oz ONZ
